Scissor Lift

– A foundation pit is needed.
– Hydraulic cylinder direct drive system- ISO9001, CE certificated.
– Double cylinder design
– High precision and stable hydraulic drive system button switch
– Small space occupation
– Pre-assembled structure makes easier installation
– Remote control is optional
– Top quality diamond steel plate
– Hydraulic overloading protection available

KEY FEATURES

1. Sturdy structure and large load-bearing capacity，High-strength materials and scissor-type mechanical structure are used to ensure the stability and high load capacity of the equipment.

2.The hydraulic drive operates smoothly and is equipped with overload safety protection devices to ensure safe operation.

3.The structure design is reasonable, the installation is convenient, the later maintenance cost is low and the service life is long.

4. Different configurations (such as size, load, control method, etc.) can be selected according to the installation environment and usage requirements to meet special working conditions.

Model	QJY-J
Lifting capacity	1000-20000kg
Lifting height	2-15 Meters
Platform size	6 M(L)X3.5M(W)
Min height	200mm
Lifting speed	4 M/Min
Drive model	Hydraulic direct drive
Motor power	3kw
Input voltage	380/415v,50hz,3-phase
Warranty	1 Year
Package	Plastic Foam, 20Container
